DASbox® Mini Bioreactor System
The DASbox is a unique mini bioreactor system suitable for microbial and cell culture as well as stem cell applications. It is designed as a 4-fold system with up to twenty-four parallel operating bioreactors. With working volumes of 60 – 250 mL the DASbox is the optimal tool for advanced process development and Design of Experiments (DoE) applications. All critical process parameters can be precisely controlled. Liquid-fre…
Receive your quote directly from the manufacturer.
The DASbox is a unique mini bioreactor system suitable for microbial and cell culture as well as stem cell applications.
It is designed as a 4-fold system with up to twenty-four parallel operating bioreactors. With working volumes of 60 – 250 mL the DASbox is the optimal tool for advanced process development and Design of Experiments (DoE) applications. All critical process parameters can be precisely controlled. Liquid-free temperature control and exhaust condensation satisfy users with easy handling.
In addition to using industry standard glass bioreactors the DASbox can be equipped with Eppendorf BioBLU® 0.3 vessels, all fully instrumented single-use mini bioreactors.
Eppendorf DASbox® Mini Bioreactor System Features:
- Parallel set-up of up to 24 bioreactors;
- Excellent scalability and reproducibility in both microbial and cell culture applications;
- Supports industry standard glass bioreactors (DASbox Mini Bioreactor) as well as the BioBLU 0.3 Single-Use Vessels;
- Small working volumes save on the amount of cell material, media and supplements required;
- Extremely compact system with a footprint of only 7.5 cm (3 in) benchspace per vessel;
- Individual temperature control with liquid-free heating and cooling (Peltier);
- Liquid-free Peltier exhaust condenser with easy handling by automatic slide in activation and slide out deactivation mode;
- LC display with key process parameters and integrated alarm function simplifies monitoring;
- Fully mass flow-controlled gas mixing with individual gas mixture from Air, O2, CO2 and N2, each directable either to headspace or sparger;
- Standard sensors for precise measurement and control of temperature, pH, DO, level and ORP (redox potential); optical pH sensors available;
- Precise miniature variable speed pumps, continuous flow rates down to 0.3 mL/h;
- Sealed magnetic overhead drives for single-use vessels and direct overhead drives for autoclavable vessels; up- or downflow selectable;
- Optional pull-out system for enhanced accessibility of bioreactors and control unit.
Applications:
- Process development in cell culture and microbiology;
- Design of Experiments (DoE) Media optimization Clone and cell line screening, strain characterization.
