CLARIOstar® Plus Multi-mode Microplate Reader
Most flexible Multi-mode Microplate Reader for Assay Development
Receive your quote directly from the manufacturer.
BMG plate readers are a great addition to any lab
Cancer Research
We have been using BMG Labtech plate readers for around 15 years now in my laboratory. We initially started with a PHERAstar Plus, but have since moved to buying two of the more flexible CLARIOStar Plus instruments to support a wide range of microtitre plate applications with greater ease (the LVF monochromator design is great!). We have been so pleased with the performance of BMG plate readers over time - they are extremely reliable and the customer support received by the BMG team is absolutely fantastic. My lab serves around 350 different scientists a year (my lab is a centralised core facility for an entire research Institute) and so reliability, flexibility and user-friendliness of the BMG equipment and software as well as excellent customer support is absolutely key. I can say that BMG excels at all.
Review Date: 9 Dec 2025 | BMG LABTECH
ClarioStar is the best plate reader you can have.
Cell based assays
I've used my Clariostar for years, its reliable, low maintainance, an I can establish new assays with such an ease, as I can scan each fluorophore. Its also so easy as I dont have to buy new filters every time I need another flurophore. What I really love about it, is that you can also upgrade with new technologies as Luminescence or Injection, so no need to buy new - which means less waste! Furthermore the support by the field an inhouse application specialists has always been timely and helpful.
Review Date: 22 Jul 2025 | BMG LABTECH
Great instrument with a wide range of capabilities, even better service.
Enzyme assays, cell based assays (Calcium flux, viability, caspase mediated apoptosis, drug/receptor assays via HTRF)
The Clariostar is simple to setup, the UI is easy to navigate and customise. It performs well, with excellent reproducibility and very fast read times. Setting up injector protocols can be tricky but the support from BMG Labtech easily overcomes any issues and their expertise and advice in these types of situations is invaluable, so too when troubleshooting is required.
Review Date: 14 Jul 2025 | BMG LABTECH
Good service, good instrument
Pharmaceuticals
Very fast delivery, good servive.
Review Date: 26 Jul 2024 | BMG LABTECH
Great plate reader!
ELISA
Great plate reader that we use for all our 96 well plate assays requiring an absorbance or fluorescent read out. Great for everything from growth curves to reading ELISAs. It has a decent absorbance/ fluorescence spectrum and the analysis software is useful and easy to use.
Review Date: 25 Jul 2024 | BMG LABTECH
Broad spectrum functionalities plate reader for advanced kinetics etc.
Microplate reading w/ kinetics and temperature gradients
Great product, very advanced settings and possibilities. Far more functions than usual plate reader. Sometimes a bit complicated because of the amount of functions.
Review Date: 25 Jul 2024 | BMG LABTECH
ClarioStar Plate Readers provide top-notch measurements with high throughput and precision
Research in Plant Physiology and Signaling
Our lab is equipped with 5 ClarioStar Plus Plate Readers, which are equipped with standard fluorescence intensity and absorbance measurement modules and additional different specific features for injections, fluorescence lifetime measurements, atmospheric control or luminescence measurements. Upon request BMG Labtech provided specific software additions for custom use purposes and are always very friendly when responding to individual questions concerning usage. The readers are highly usable in different research areas within our research group. The device and software are easy to use, and thus can not only be used in research, but also for student teaching courses on fluorescent biosening. The readers provides high quality data with top-notch precision at a high throughput level. In our opinion the BMG LABtech readers are the best available device of this kind on the market.
Review Date: 24 Jul 2024 | BMG LABTECH
Very good product, reliable and easy to use.
Materials Science
I have used the CLARIOstar Plus platereader since 2021 and the overall experience has always been good. I used it to run fluorescence and absorbance assays and it always proved to be reliable and easy to use. When one part of the machine broke, it was repaired in less than one week by the BMG technicians.
Review Date: 24 Jul 2024 | BMG LABTECH
Very good and useful instrument
Fluorescence polarization
The instrument design and operation are user friendly. Software usage is self explanatory, but it needs training to master it. Sensitivity and results reproducibility are the best characteristics. It is also easy to do maintenance.
Review Date: 24 Jul 2024 | BMG LABTECH
Excellent product
Microbiology
Very user friendly device with multimodal assay options that are easy to programme. Excellent customer service for all devices. Really quick and helpful answers are provided by the BMG team.
Review Date: 24 Jul 2024 | BMG LABTECH
The CLARIOstar® Plus is the most-sensitive monochromator-based microplate reader.. This high-performance multi-mode microplate reader from BMG LABTECH is equipped with revolutionary LVF MonochromatorsTM, spectrometer, and filters. Patented LVF Monochromators™ include cutting-edge technology, such as linear variable filters and a linear variable dichroic mirror. These provide the highest flexibility while delivering filter-like performance for fluorescence and luminescence assays including FRET and BRET. There is no compromise when it comes to sensitivity and flexibility, making the CLARIOstar Plus the leading microplate reader in its class. The Enhanced Dynamic Range and autofocus technologies significantly improve usability, making manual settings superfluous and detection optimisation easier than ever.
Features of the CLARIOstar Plus multi-mode microplate reader include:
- LVF Monochromators™ with continuously adjustable bandwidths from 8 to 100 nm allow more light for excitation and emission, resulting in greater sensitivity
- Largest dynamic range with no manual intervention - Rapid full-plate autofocus
- Increased flexibility with dedicated detectors
- Top and bottom reading for fluorescence and luminescence assays using monochromators or filters
- Combine filters and monochromators in the same measurement for higher flexibility in any fluorescence or luminescence assay
- High-speed, full spectrum UV/vis absorbance (220 to 1000 nm in < 1 second per well)
- Advanced detection modes: fluorescence polarization, time-resolved fluorescence, TR-FRET and AlphaScreen®
- Dedicated, high-energy laser for AlphaScreen® and AlphaLISA® assays
- Dedicated features for live cell-based assays including Atmospheric Control Unit
- Ultra-fast data sampling (100 measurements/second) for fast kinetics
The Atmospheric Control Unit (ACU) allows independent, simultaneous control of both O2 and CO2 within the microplate reader chamber. Ranging from standard cell growth assays to cytotoxicity assays, the ACU provides the optimal environment for any live cell-based assay. As a unique function, the CLARIOstar Plus with ACU can run gas ramps and mimic pathological conditions such as ischemia/reperfusion and hypoxia in vitro.
Accessories
- Atmospheric Control Unit (ACU): provides the ideal environment for cell-based assays by regulating O2 and CO2 gas levels in the microplate reader
- Filters and Optic Modules: standard filters from 240 - 850 nm, filters and Optic Modules optimised for specific applications, and bespoke solutions are available
- Microplate Stacker: optimises microplate handling and increases throughput by providing rapid loading, unloading, restacking, and continuous feeding for up to 50 microplates
- LVis Plate: microplate for low-volume DNA, RNA and protein quantification. It includes 16 micro-drop (2 µL) wells, a cuvette slot and optional performance testing features
- Evaluation Plate: validates the optical functionality of BMG LABTECH microplate readers for quality control and/or qualification (IQ/OQ) purposes
