Products & ReviewSpectroscopy
Golden Gate® diamond ATR
Specac LtdGS10500
The Golden Gate® is a robust option for demanding single-reflection ATR applications. It features a brazed diamond ATR crystal and a signature “Golden Gate” sample loading bridge. More advanced top-plate assemblies are available for in-situ, high- and low-temperature work.
The supplier does not provide quotations for this product through SelectScience. You can search for similar products in our Product Directory.
Description
The Golden Gate® is a robust option for demanding single-reflection ATR applications. It features a brazed diamond ATR crystal and a signature “Golden Gate” sample loading bridge. More advanced top-plate assemblies are available for in-situ, high- and low-temperature work.
Features
- Monolithic diamond ATR The diamond crystal is brazed into a tungsten carbide mounting to achieve the highest possible physical and chemical resilience.
- Robust sampling top-plates The stainless-steel top-plate joins the diamond crystal and the loading bridge into one integral part that can withstand anything the lab throws at it. There are also top-plate options for in-situ sampling at sub-zero or high temperatures up to 300 °C.
- Signature bridge design Up to 80 lbs force can be applied to solid samples, ensuring the firmest possible contact to the diamond.
- Sapphire anvil The standard anvil tip for loading solid samples is made from durable sapphire and is self-levelling to deal with irregularly shaped solids. There are also anvils for dealing with polymer beads, wires, and textile fibres.
