ZORBAX 80Å StableBond columns are made using bulky, patented, unique silanes that sterically protect the siloxane bond. Acid labile endcapping reagents are not used. The result is vastly improved column life and extraordinary chemical and temperature stability in the pH 1–6 range for a wide variety of phases (SB-Aq, SB-C3, SB-CN, SB-Phenyl, SB-C8, and SB-C18).

400 bar; available in 2.1 - 4.6 mm id; 30, 50, 75, 100, 150 mm lengths. Manufactured by Agilent to rigorous QC specifications, the ZORBAX family encompasses 5 particle sizes and more than 32 phases, for reliable scalability and transferability from HPLC to UHPLC, from lab to lab and around the world.

Agilent ZORBAX Eclipse XDB columns – C18, C8, Phenyl and CN – provide four bonded phase choices for method development optimization. These columns provide good peak shape over a wide pH range (2–9) for additional method development flexibility with one family of columns.

Eclipse Plus columns provide the ultimate in performance for silica-based columns. Peak shape for the Eclipse Plus is excellent for the most challenging basic compounds, improving efficiency and resolution with these sample types.

Agilent Mass Profiler Professional (MPP) software is a powerful chemometrics platform designed to exploit the high information content of MS data and can be used in any MS-based differential analysis to determine relationships among two or more sample groups and variables.

The 1260 Infinity II Bio-Inert Pump is a quaternary UHPLC pump that is made of bio-inert material for use in biological and extreme pH applications. This pump enables gradient formation and solvent blending from up to four solvents and operates at pressures up to 600 bar and flow rates up to 10 mL/min.

The 1260 Infinity II Preparative Fraction Collector is optimized for laboratories performing semipreparative-scale purification of milligram to low gram quantities with typical flow rates between 4 and 100 mL/min. The module features the full set of collection modes and is compatible with a wide variety of trigger sources. SBS plates and four different tube sizes with various lengths are supported.

The 1260 Infinity III Manual Injector is an HPLC valve for manual injection of samples at pressures up to 600 bar. It is supplied with a baseplate, which is dimensioned to match the footprint of all 1260 Infinity modules. The 1260 Infinity III Manual Injector is a compact, affordable solution for sample injection.

The diode array design of the 1260 Infinity III Multiple Wavelength Detector offers very low detector noise (less than ±7 μAU) for precise quantification of trace levels, regardless of the number of signals recorded. Over a wavelength range from 190 to 950 nm, simultaneous detection of up to eight compound-specific wavelengths for optimum selectivity is provided.

The 1260 Infinity II Preparative Autosampler is designed for automated sample handling in routine purification applications. This flow-through vialsampler supports preparative flow rates of 200 mL/min and 600 bar pressure. Increase your daily throughput of purified sample by injecting up to 132 preparative samples with a maximum of 3.6 mL volume.

The 1260 Infinity II Preparative Binary Pump is an affordable high-pressure gradient pump for LC purification. The pump offers a dynamic flow rate range from 1 to 50 mL/min at up to 420 bar, allowing workflows on columns from 9.4 to 30 mm inner diameter.

The 1260 Infinity III Quaternary Pump is a gradient pump that uses low-pressure mixing for UHPLC gradient formation and solvent blending from up to four solvents. This pump operates at pressures up to 600 bar and flow rates up to 10 mL/min.

The 1290 Infinity II Refractive Index Detector (RID) is a UHPLC RID detector that provides excellent sensitivity, resolution, and sample throughput for UHPLC DRI experiments. The 1290 Infinity II RID is a equipped with an ultralow dispersion microflow cell and a data rate of 148 Hz, which significantly reduces run times for higher sample throughput and improved resolution and sensitivity.

The 1260 Infinity III Variable Wavelength Detector enables highest productivity with fast analysis at up to 120 Hz data rates. Even more sample information can be acquired in dual-wavelength mode. Time-programmable wavelength switching provides optimum sensitivity and selectivity for your applications.

The 1260 Infinity II Degasser is suitable for analytical applications with flow rates up to 10 mL/min and up to four solvents. It is highly recommended for GPC/SEC applications using refractive index detection. It reduces baseline noise and quenching effects due to high degassing capacity.

Agilent has what you need for precise, effective, sample delivery from your GC autosampler.

Autosampler and Manual Syringes   For exacting measurement, transport and delivery of liquids necessary for sample preparation and injection, specify Agilents full suite of manual and autosampler syringes.  Designed for accuracy, reliability and ease of use, Agilent syringes enhance productivity and performance through every step of your sample processing.

Employing the easy release clamping design, these fittings offer a quick and simple solution to vacuum system design and assembly. Bakeable to 150º C when using Viton O-Rings, these fittings are ideal for roughing or high vacuum applications.

HTS and HTC PAL Syringes   To better serve Agilent instrument users who choose CTC Analytics autosamplers for high-throughput and flexible sample introduction, Agilent has partnered with CTC to provide a fully integrated system, including CTC-approved x-type syringes designed specifically for HTS and HTC PAL.

HTS and HTC PAL Valve Supplies   To better serve Agilent instrument users who choose CTC Analytics autosamplers for high-throughput and flexible sample introduction, Agilent has partnered with CTC to provide a fully integrated system, including CTC-approved valve supplies.Whether your HTS or HTC PAL autosampler uses the Agilent proprietary Rheodyne high-pressure 600-bar injection valve or Valco Cheminert injection valves, Agil…

HTS and HTC PAL Vials and Caps      To better serve Agilent instrument users who choose CTC Analytics autosamplers for high-throughput and flexible sample introduction, Agilent has partnered with CTC to provide a fully integrated system, including CTC-approved vials and caps for HTS and HTC PAL.

Many of Agilent’s manual syringes have color-coded barrels to facilitate volume selection while making life in the lab more colorful. For fast, easy identification, each denomination (0.5 µL to 50 mL) features a distinct color boldly embossed on the glass barrel.

LC Manual Syringes with PTFE-Tipped Plungers

Liners are sealed in the inlet with O-rings or graphite seals.

Even small leaks in the split/splitless injection port can reduce system sensitivity, cause poor signal to noise ration, increase column bleed, and even shorten column lifetime. Using a patent pending manufacturing process, our inlet gold seals eliminate tiny leaks from machining that can negatively impact your GC performance.
